Frequently Asked Questions
If I share and move a drawing to a folder, will it affect other users?
If it is a private drawing at Home, it will not affect other users. Every user is free to organize or move their drawing to any folders without affecting another user.
If the drawing is in a Team, then the entire team will be affected.
What happens if a user trashed the drawing I shared to them?
If an Owner trashed a drawing, then the shared drawing will also be trashed for other users.
Otherwise, the drawing will only be trashed for that particular user who trashed the drawing, while all other users will not be affected.
Can a user create a new drawing from shared drawing?
Yes. All users with Owner or Edit and share permissions can duplicate a drawing.
See also
How to check if the drawing belongs to personal or team in the editor?
By hovering over the icon at the bottom left of the editor, users can see whether the drawing belongs to a Team and which Team, or if it's a personal drawing.
Can Capital Electra X generate a From/To report?
Yes, in its latest version, Capital Electra X can generate a From/To report. We call this a Connection Report.
I already have CAD symbols in AutoCad, can I import them into Capital Electra X?
Sure, you can simply drag and drop your AutoCAD drawing into Capital Electra X. Once imported, these symbols and drawings can be used in Capital Electra X to create native symbols using Create Symbol or Create Layout Symbol.
How to import drawing from Capital Electra X to Capital Electra (Offline version) and vice versa?
Importing drawing From Capital Electra X to Capital Electra (Offline version)
In the Capital Electra X toolbar, go to File | Download to download the whole drawing. The drawing will be in SVG format.
Then, drag and drop the SVG file into Capital Electra (Offline version) to import the drawing.
Importing drawing From Capital Electra (Offline version) to Capital Electra X
Click File | Save or Save as to save your file in Capital Electra (Offline version).
Go to Capital Electra X and open a new drawing. Then, drag and drop the SVG file into the Editor to import the file.
How to use an existing drawing as a template in Capital Electra (Offline version)?
All Capital Electra (Offline version) drawings can be used as a template. Please follow the steps below to create a new drawing from a template:
- Open an existing Capital Electra (Offline version) drawing.
- Click File | Save as to save it as a new drawing from the template.
How to delete my account?
If you wish to have your account deleted, you may submit your request directly to us at support@radicasoftware.com and we will take care of it for you.
Please note that all data will be erased upon the removal of your account.
